Accton ACS4116-16GT2GT 16-Port Cloud Managed Gigabit PoE Switch

The Accton ACS4116-16GT2GT is a cloud-managed gigabit PoE switch with 16 PoE ports, 2 upstream gigabit RJ45 ports and 1 gigabit SFP port. It detects IEEE 802.3af/at devices automatically and provides up to 30W per port from a 240W built-in power supply.

The all-metal body, overcurrent / overload / short-circuit protection and common- and differential-mode lightning protection make it suitable for continuous CCTV and network installations.

Key Features

• Ports: 16 × 10/100/1000M PoE RJ45, 2 × 10/100/1000M uplink RJ45, 1 × 1000M SFP
• PoE: IEEE 802.3af/at, up to 30W per port, 240W total; compatible with certified non-standard PD
• Backplane bandwidth: 38G; MAC address table: 2K; forwarding rate: 28.272Mpps
• Cloud management: view SN, model, firmware, real-time port power, link and speed; port restart, PoE switch, long-distance mode, firmware upgrade
• Surge protection: 4KV differential and common mode (10/700μs)
• Overcurrent, overload and short-circuit protection; sequential PoE start-up; soft start for high-power PD
• Auto MDI/MDI-X on all ports, IEEE 802.3x flow control, automatic MAC learning and aging
• Power: AC 100–250V, 240W single power supply; PoE line sequence 1/2, 3/6, 4/5, 7/8
• Environment: 0°C to 40°C operating, -40°C to 70°C storage, 10%–90% RH non-condensing
• Weight: approx. 0.75kg (bare unit)

Ideal For

Medium CCTV systems, hotels, shops and offices powering up to 16 PoE cameras or access points with a fibre or switch uplink.
